Allen-Bradley POINT I/O 1734-ADN - Specifications

POINT I/O 3
Publication 1734-IN510B-EN-P - August 2000
Wiring Diagrams
Specifications
General specifications - These specifications are shared by all components of the 1734 POINT I/O system.
1734-TB, -TBS, -TB3 and -TB3S Specifications
Out
0
Out
1
Out
1
Out
0
CC
VV
Load Load
42014
V = 12/24V dc, C = Common
Field power is supplied from power bus
1734-OB2E
Out
0
Out
1
Out
3
Out
2
CC
CC
Load Load
42015
Load Load
V = 12/24V dc, C = Common
Field power is supplied from power bus
1734-OB4E
In
0
In
1
CC
VV
In 0 In 1
V = 12/24V dc, C = Common Chass GND = Chassis Ground
This supply will be connected to the internal power bus.
42017
1734-IE2C
42018
Out
0
Out
1
CC
VV
Out 0 Out 1
V = 12/24V dc, C = Common
Chass GND = Chassis Ground
This supply will be connected to
the internal power bus.
1734-OE2C
Load
Out
0A
C
VV
C
Load
V = 12/24V dc, C = Common
This supply will be connected to
the internal power bus.
Out
1A
Out
1B
Out
0B
42019
1734-OW2
0
4
2
6
1
5
3
7
0
4
2
6
1
5
3
7
0
4
2
6
1
5
3
7
0
4
2
6
1
5
3
7
0
4
2
6
1
5
3
7
Chass
Gnd
Chass
Gnd
Chass
Gnd
Chass
Gnd
A Anot
B
Z
FE FE
Znot
Bnot
A, B, Z, Anot, Bnot,
and Znot = inputs
FE = Functional Earth
41975
0
4
2
6
1
5
3
7
1734-IJ, & 1734-IK
A Anot
B
Z
Out 0 Out 1
Znot
Bnot
A, B, Z, Anot, Bnot, and Znot = inputs
FE = Functional Earth
-Vaux = Auxiliary Supply
+Vaux = Auxiliary Supply
42444
FE FE
RET 0
-Vaux -Vaux
RET 1
+Vaux +Vaux
1734-VHSC24, &
1734-VHSC5
0
4
2
6
1
5
3
7
0
4
2
6
1
5
3
7
Specification: Value: Specification: Value:
Environ. Conditions
Operating Temp.
Storage Temp.
Relative Humidity
Shock Operating
Non-operating
Vibration
-20 to 55
o
C (-4 to 131
o
F)
-40 to 85
o
C (-40 to 185
o
F)
5 to 95% noncondensing
30g peak acceleration, 11(±1)ms pulse width
50g peak acceleration, 11(±1)ms pulse width
Tested 5g @ 10-500Hz per IEC 68-2-6
Conductors
Wire Size
Category
14 AWG (2.5mm
2
) - 22 AWG (0.25mm
2
)
solid or stranded max
(18 AWG max if connecting 2 wires to same terminal)
3/64 inch (1.2mm) insulation max
2
1
Terminal Base Screw
Torque
7 inch-pounds max Agency Certification
(When Product or
Packaging is Marked)
CE marked for all applicable directives
C-Tick marked for all applicable acts
CUL listed – Class I, Division 2
Groups A, B, C and D certified
CUL recognized
DeviceNet conformance tested
1
Use this conductor category information for planning conductor routing as described in the system level installation manual.
Specification: 1734-TB, -TBS, -TB3, -TB3S Specification: 1734-TB, -TBS, -TB3, -TB3S
Field Power Bus
Voltage 240V ac (1734-TB, -TBS)
28.8V dc, 120/240V ac (1734-TB3, -TB3S)
Dimensions
(HxWxL)
65mm x 12mm x 133.4mm
(2.560in x 0.472in x 5.250in) (1734-TB, -TBS)
65mm x 12mm x 160mm
(2.560in x 0.472in x 6.25in) (1734-TB3, -TB3S)
Current 10A max Mass 2.94 oz/83.35 grams (1734-TB)
2.57 oz/73.86 grams (1734-TBS)
3.44 oz/97.5 grams (1734-TB3)
3.07 oz/87 grams (1734-TB3S)
