POINT I/O 5
Publication 1734-IN510B-EN-P - August 2000
1734-FPD Specifications
1734-AC Input Modules (1734-IA2
1
, -IM2
2
)
Inrush Current 6A for 5ms Power Consumption 7.0W max @ 25V dc
Pointbus Output Current 1A maximum @ 5V dc +
5% (4.75-5.25) Mass 4.56 oz/129.28 grams
Isolation Voltage 1528V rms/V ac
Specification Value: Specification Value:
Specification Value: Specification Value:
Pointbus Output Current Pass through Indicators None
Input Current 10A max Inrush Current 10A max
Module Location Between I/O modules in 1734 system
Breaks power bus
Dimensions
(HxWxL)
76.2mm x 25.4mm x 133.4mm
(3.00in x 1.00in x 5.25in)
Field Power Bus
Voltage
Current
264V ac max
12V dc, 24V dc/120V ac or 240V ac
10A max
Power Supply 0 - No connection 4 - Common
1 - No connection 5 - Common
2 - Ground 6 - Supply
3 - Ground 7 - Supply
Input Voltage Rating 12V dc, 24V dc, 120V ac, 240V ac nominal Mass 4.38 oz/124.17 grams
Specification Value Specification Value
Module Location 1734-TB, -TBS, -TB3 or -TB3S wiring base assembly Pointbus Current 75mA maximum @ 5V dc
Power Dissipation 0.7W maximum @ 28.8V dc Thermal Dissipation 2.4 BTU/hr maximum @ 28.8V dc
Isolation Voltage Tested at 1250V rms/V for 1s (1734-IA2)
Tested at 1500V rms/V for 1s (1734-IM2)
Dimensions Inches
(Millimeters)
2.21H x 0.47W x 2.97L
(56.0H x 12.0W x 75.5L)
External AC Power Supply
Voltage
120V ac, 60Hz nominal (1734-IA2)
220V ac, 60Hz nominal (1734-IM2)
External AC Power Supply
Voltage Range
85-132V ac, 47-63Hz (1734-IA2)
159-264V ac, 47-63Hz (1734-IM2)
Field Wiring Terminations 0 - Input 0 1 - Input 1
2 - No Connection 3 - No Connection
4 - L2N 5 - L2/N
6 - L1 7 - L1
Mass 1.09 oz/30.90 grams
Input Specifications (1734-IA2, -IM2)
Number of Inputs 2 (1 group of 2) non-isolated, sinking OFF-State Voltage 43V ac maximum
ON-State Voltage 1734-IA2
1734-IM2
65V ac minimum 159V ac minimum
120V ac nominal 220V ac nominal
ON-State Current 1734-IA2
1734-IM2
3.7mA minimum 5.7mA minimum
6.9mA nominal @ 120V ac, 60Hz 8.0mA nominal
OFF-State Current 2.5mA maximum (1734-IA2)
2.9mA maximum (1734-IM2)
Nominal Input Impedance 10.6kΩ (1734-IA2)
22.3kΩ (1734-IM2)
Delay Time
3
OFF to ON and
ON to OFF
20ms hardware filter plus 1ms - 64ms digital filter
programmable in increments of 1ms
Indicators 2 yellow input status, logic side
1 green/red network status, logic side
1 green/red module status, logic side
Keyswitch Position 8
1
This module is IEC3 120V ac input compliant.
2
This module is IEC3 220V ac input compliant.
3
Off/on delay is time from a valid output “on” signal to output energization. On/off delay is time
from a valid output “off” signal to output deenergization.
