Allen-Bradley POINT I/O 1734-AENT User Manual

6 POINT I/O EtherNet/IP Adapter
Publication 1734-IN042F-EN-P - November 2018
About the Adapter
The Series C 1734-AENT and 1734-AENTK POINT I/O™ EtherNet/IP Adapter are
communications adapters for POINT I/O modules.
The adapter provides an interface for controlling and communicating with POINT I/O
modules from an EtherNet/IP network.
POINT I/O EtherNet/IP Adapter, Series C
WARNING: Secure any external connections that mate to this equipment by
using screws, sliding latches, threaded connectors, or other means provided
with this product.
WARNING: Do not disconnect equipment unless power has been removed
or the area is known to be nonhazardous.
WARNING: Enclosure must be marked with the following: “Warning - Do
not open when energized.” After installation of equipment into the
enclosure, access to termination compartments shall be dimensioned so that
conductors can be readily connected.
31533
Module
S
tatus
Networ
k
Activity
N
e
t
w
or
k
Status
Point Bus
S
tatus
System
Power
Field
Po
wer
POINT I O
1
7
3
4
-
A
EN
T
02
0
1
7
3
5
6
2
4

Allen-Bradley POINT I/O 1734-AENT Specifications

General

Manufacturer	Allen-Bradley
Product Line	POINT I/O
Catalog Number	1734-AENT
Category	Adapter
Communication	EtherNet/IP
Shock	30 g
Enclosure Type Rating	None (open-style)
Input Voltage	24V DC nominal
Housing Material	Plastic
Mounting Type	DIN Rail
IP Rating	IP20
Operating Temperature	-20°C to 60°C
Storage Temperature	-40°C to 85°C
Relative Humidity	5% to 95% non-condensing
Vibration	5 g @ 10-500 Hz
Ethernet Port	10/100 Mbps
Power Consumption	3.5 W max
Number of Ports	2
Series	A
