POINT I/O EtherNet/IP Adapter 7
Publication 1734-IN042F-EN-P - November 2018
Before You Begin
To effectively use your adapter, note the following considerations.
Firmware Backward Compatibility
The 1734-AENT and 1734-AENTK Add-on Profiles are compatible with
RSLogix 5000® software version 17, or greater.
If you use the 1734-AENT or 1734-AENTK adapter with a 1756-ENBT module, use the
following required firmware versions for these bridge modules:
• 1756-ENBT firmware version 4.006 or greater
• 1768-ENBT firmware version 2.003 or greater
Add-on Profiles can be downloaded from:
https://www.rockwellautomation.com/rockwellautomation/support/downloads.page
Understand Messaging
Class 3 (Explicit Message) requests through the 1734-AENT or 1734-AENTK adapter to
a specific POINT
I/O module do not always receive a response from the I/O modules.
Where an I/O module does not reply to a request, the adapter responds with an error code
indicating a timeout.
Configure Autobaud
The adapter cannot reconfigure an I/O module that you previously configured to operate
at a fixed baud rate. When you reuse a POINT I/O module from another POINT I/O
system, configure the module to autobaud before using it with the adapter.
Description Description
1 Safety end Cap 5 Ethernet network RJ-45 connector
2 Removable Terminal Block (RTB) handle 6 Network address thumbwheel
3 Removable Terminal Block (RTB) 7 Status indicators
4 DIN rail locking screw (orange)
