318 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 6 Troubleshooting
224
225
226
227
228
229
230
231
232
233
234
Port 4 Comm Loss
Port 5 Comm Loss
Port 6 Comm Loss
Port 7 Comm Loss
Port 8 Comm Loss
Port 9 Comm Loss
Port10 Comm Loss
Port11 Comm Loss
Port12 Comm Loss
Port13 Comm Loss
Port14 Comm Loss
Resettable Fault Coast The device at the port has stopped communicating with the main
control board.
Verify that the device is present and functional.
Verify network connections.
Verify options that are installed in ports 4…8 are seated in the port
and secured with mounting screws.
244
245
246
247
248
249
250
251
252
253
254
Port 4 Cfg
Port 5 Cfg
Port 6 Cfg
Port 7 Cfg
Port 8 Cfg
Port 9 Cfg
Port 10 Cfg
Port 11 Cfg
Port 12 Cfg
Port 13 Cfg
Port 14 Cfg
Alarm 2 The main control board does not have the correct option in the port.
Option may not be compatible with product or MCB firmware must be
updated to support it. Option may have to be moved or removed,
accept option configuration change.
264
265
266
267
268
269
270
271
272
273
274
Port 4 Checksum
Port 5 Checksum
Port 6 Checksum
Port 7 Checksum
Port 8 Checksum
Port 9 Checksum
Port10 Checksum
Port11 Checksum
Port12 Checksum
Port13 Checksum
Port14 Checksum
Resettable Fault Coast An option module storage checksum failed.
Option data has been set to default values.
281 Enet Checksum Resettable Fault Coast EtherNet/IP storage checksum failed. Data set to default values.
282 DLX Checksum Resettable Fault Coast DeviceLogix storage checksum failed. Data set to default values.
290 Prev Maint Reset Alarm 1 Predictive maintenance function has reset an elapsed life parameter.
291 HSFan Life Configurable 493
[HSFan EventActn] Predictive maintenance function has reached the event level. Perform
maintenance.
292 InFan Life Configurable 500 [InFan EventActn]
293 MtrBrng Life Configurable 506
[MtrBrngEventActn]
294 MtrBrng Lube Configurable 510
[MtrLubeEventActn]
295 MachBrng Life Configurable 515 [MtrBrngEventActn]
296 MachBrng Lube Configurable 519
[MchLubeEventActn]
307 Port7InvalidCard Non-Reset Fault Coast Option not valid in that port. Remove option module.
308 Port8InvalidCard Non-Reset Fault Coast
310 Regeneration OK Resettable Fault Coast The drive has detected that the 'Regeneration OK' input has transition
to an ‘inactive’ state.
315 Excess Psn Err Configurable Configured with Logix
controller.
The absolute maximum Position Error value has been exceeded.
318
319
320
OutCurShare PhU
OutCurShare PhV
OutCurShare PhW
Alarm 1 There is output current sharing imbalance between parallel inverters
in the phase indicated that is greater than 15 % of the inverter rated
current.
Event
No.
Fault/Alarm Text Type Fault
Action
Configuration
Parameter
Auto
Reset
Description/Action(s)
