Allen-Bradley PowerFlex 70 Reference Manual

Fuses and Circuit Breakers 2-103
Table 2.P PF700 208 Volt AC Input Protection Devices
Table 2.Q PF700 240 Volt AC Input Protection Devices
See page 2-105 for Notes.
Drive
Catalog
Number
Frame
HP
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
208 Volt AC Input
20BB2P2 0 0.5 0.33 4 50 1.9 0.7 2.5 2.8 3.8 3 6 3 10 15 3 M-C2E-B25 M-D8E-B25 – –
20BB4P2 0 1 0.75 4 50 3.7 1.3 4.8 5.6 7.0 6 10 6 17.5 15 7 M-C2E-B63 M-D8E-B63 – –
20BB6P8 1 2 1.5 4 50 6.8 2.4 7.8 10.4 13.8 10 15 10 30 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BB9P6 1 3 2 4 50 9.5 3.4 11 12.1 17 12 20 12 40 40 15 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BB015 1 5 3 4 50 15.7 5.7 17.5 19.3 26.3 20 35 20 70 70 30 M-C2E-C20 M-D8E-C20 M-F8E-C20 –
20BB022 1 7.5 5 4 50 23.0 8.3 25.3 27.8 38 30 50 30 100 100 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BB028 2 10 7.5 4 50 29.6 10.7 32.2 38 50.6 40 70 40 125 125 50 – – M-F8E-C32 -CMN-4000
20BB042 3 15 10 4 50 44.5 16.0 48.3 53.1 72.5 60 100 60 175 175 70 – – M-F8E-C45 -CMN-6300
20BB052 3 20 15 4 50 51.5 17.1 56 64 86 80 125 80 200 200 100 – – – -CMN-6300
20BB070425204507225.978.2931249017590300300100–––-CMN-9000
20BB080 4 30 25 4 50 84.7 30.5 92 117 156 110 200 110 350 350 150 – – – -CMN-9000
20BB104 5 40 – 4 50 113 40.7 120 132 175 150 250 150 475 350 150 ––––
–3045084.730.592 138175125200125350300150–––-CMN-9000
20BB130 5 50 – 4 50 122 44.1 130 143 175 175 275 175 500 375 250 – – – –
– 40 4 50 98 35.3 104 156 175 125 225 125 400 300 150 – – – –
20BB154660–45016760.1177195266225350225500500250––––
–5045014150.9150225300200300200500450250––––
20BB192 6 75 – 4 50 208 75.0 221 243 308 300 450 300 600 600 400 – – – –
– 60 4 50 167 60.1 177 266 308 225 350 225 500 500 250 – – – –
Drive
Catalog
Number
Frame
HP
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
240 Volt AC Input
20BB2P2 0 0.5 0.33 4 50 1.7 0.7 2.2 2.4 3.3 3 6 3 10 15 3 M-C2E-B25 M-D8E-B25 – –
20BB4P2 0 1 0.75 4 50 3.3 1.4 4.2 4.8 6.4 5 8 5 15 15 7 M-C2E-B63 M-D8E-B63 – –
20BB6P8 1 2 1.5 4 50 5.9 2.4 6.8 9 12 10 15 10 25 25 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BB9P6 1 3 2 4 50 8.3 3.4 9.6 10.6 14.4 12 20 12 35 35 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BB015 1 5 3 4 50 13.7 5.7 15.3 16.8 23 20 30 20 60 60 30 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BB022 1 7.5 5 4 50 19.9 8.3 22 24.2 33 25 50 25 80 80 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BB028 2 10 7.5 4 50 25.7 10.7 28 33 44 35 60 35 100 100 50 – – M-F8E-C32 -CMN-4000
20BB042 3 15 10 4 50 38.5 16.0 42 46.2 63 50 90 50 150 150 50 – – M-F8E-C45 -CMN-6300
20BB052 3 20 15 4 50 47.7 19.8 52 63 80 60 100 60 200 200 100 – – – -CMN-6300
20BB0704252045064.226.770781059015090275275100–––-CMN-9000
20BB080 4 30 25 4 50 73.2 30.5 80 105 140 100 180 100 300 300 100 – – – -CMN-9000
20BB104540–45098 40.6104115175125225125400300150––––
–3045073 30.580120160100175100300300100–––-CMN-9000
20BB130 5 50 – 4 50 122 50.7 130 143 175 175 275 175 500 375 250 – – – –
– 40 4 50 98 40.6 104 156 175 125 225 125 400 300 150 – – – –
20BB154660–45014560.1154169231200300200600450250––––
–5045012250.7130195260175275175500375250––––
20BB192 6 75 – 4 50 180 74.9 192 211 288 225 400 225 600 575 250 – – – –
– 60 4 50 145 60.1 154 231 308 200 300 200 600 450 250 – – – –

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
