Allen-Bradley PowerFlex 70 Reference Manual

2-104 Fuses and Circuit Breakers
Table 2.R PF700 400 Volt AC Input Protection Devices
Table 2.S PF700 480 Volt AC Input Protection Devices
See page 2-105 for Notes.
Drive
Catalog
Number
Frame
kW
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable
Current Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
400 Volt AC Input
20BC1P3 0 0.37 0.25 4 50 1.1 0.77 1.3 1.4 1.9 3 3 3 6 15 3 M-C2E-B16 – – –
20BC2P1 0 0.75 0.55 4 50 1.8 1.3 2.1 2.4 3.2 3 6 3 8 15 3 M-C2E-B25 M-D8E-B25 – –
20BC3P5 0 1.5 0.75 4 50 3.2 2.2 3.5 4.5 6.0 6 7 6 12 15 7 M-C2E-B40 M-D8E-B40 – –
20BC5P0 0 2.2 1.5 4 50 4.6 3.2 5.0 5.5 7.5 6 10 6 20 20 7 M-C2E-B63 M-D8E-B63 – –
20BC8P7 0 4 2.2 4 50 7.9 5.5 8.7 9.9 13.2 15 17.5 15 30 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BC011 0 5.5 4 4 50 10.8 7.5 11.5 13 17.4 15 25 15 45 45 15 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BC015 1 7.5 5.5 4 50 14.4 10.0 15.4 17.2 23.1 20 30 20 60 60 20 M-C2E-C20 M-D8E-C20 M-F8E-C20 –
20BC022 1 11 7.5 4 50 20.6 14.3 22 24.2 33 30 45 30 80 80 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 –
20BC030 2 15 11 4 50 28.4 19.7 30 33 45 35 60 35 120 120 50 – – M-F8E-C32 –
20BC037 2 18.5 15 4 50 35.0 24.3 37 45 60 45 80 45 125 125 50 – – M-F8E-C45 –
20BC043 3 22 18.5 4 50 40.7 28.2 43 56 74 60 90 60 150 150 60 – – – –
20BC056 3 30 22 4 50 53 36.7 56 64 86 70 125 70 200 200 100 – – – –
20BC072 3 37 30 4 50 68.9 47.8 72 84 112 90 150 90 250 250 100 – – – –
20BC085 4 45 – 4 45 81.4 56.4 85 94 128 110 200 110 300 300 150 – – – –
– 37 4 45 68.9 47.8 72 108 144 90 175 90 275 300 100 – – – –
20BC105 5 55 – 4 50 100.5 69.6 105 116 158 125 225 125 400 300 150 – – – –
– 45 4 50 81.4 56.4 85 128 170 110 175 110 300 300 150 – – – –
20BC125 5 55 – 4 50 121.1 83.9 125 138 163 150 275 150 500 375 250 – – – –
– 45 4 50 91.9 63.7 96 144 168 125 200 125 375 375 150 – – – –
20BC140 5 75 – 4 40 136 93.9 140 154 190 200 300 200 400 400 250 – – – –
– 55 4 40 101 69.6 105 157 190 150 225 150 300 300 150 – – – –
20BC170 6 90 – 4 50 164 126 170 187 255 250 375 250 600 500 250 – – – –
– 75 4 50 136 103 140 210 280 200 300 200 550 400 250 – – – –
20BC205 6 110 – 4 40 199 148 205 220 289 250 450 250 600 600 400 – – – –
– 90 4 40 164 126 170 255 313 250 375 250 600 500 250 – – – –
20BC260 6 132 – 2 40 255 177 260 286 390 350 550 350 750 750 400 – – – –
– 110 2 40 199 138 205 308 410 250 450 250 600 600 400 – – – –
Drive
Catalog
Number
Frame
HP
Rating
PWM
Freq. Temp.
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-Time
Delay Fuse
Circuit
Breaker
(3)
Motor
Circuit
Protector
(4)
140M Motor Starter with Adjustable Current
Range
(5)(6)
ND HD kHz °C Amps kVA Cont. 1 Min. 3 Sec. Min.
(1)
Max.
(2)
Min.
(1)
Max.
(2)
Max.
(8)
Max.
(8)
Available Catalog Numbers - 140 . . .
(7)
480 Volt AC Input
20BD1P1 0 0.5 0.3
3
4 50 0.9 0.7 1.1 1.2 1.6 3 3 3 6 15 3 M-C2E-B16 – – –
20BD2P1 0 1 0.7
5
4 50 1.6 1.4 2.1 2.4 3.2 3 6 3 8 15 3 M-C2E-B25 – – –
20BD3P4 0 2 1.5 4 50 2.6 2.2 3.4 4.5 6.0 4 8 4 12 15 7 M-C2E-B40 M-D8E-B40 – –
20BD5P0 0 3 2 4 50 3.9 3.2 5.0 5.5 7.5 6 10 6 20 20 7 M-C2E-B63 M-D8E-B63 – –
20BD8P0 0 5 3 4 50 6.9 5.7 8.0 8.8 12 10 15 10 30 30 15 M-C2E-C10 M-D8E-C10 M-F8E-C10 –
20BD011 0 7.5 5 4 50 9.5 7.9 11 12.1 16.5 15 20 15 40 40 15 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BD014 1 10 7.5 4 50 12.5 10.4 14 16.5 22 17.5 30 17.5 50 50 20 M-C2E-C16 M-D8E-C16 M-F8E-C16 –
20BD022 1 15 10 4 50 19.9 16.6 22 24.2 33 25 50 25 80 80 30 M-C2E-C25 M-D8E-C25 M-F8E-C25 -CMN-2500
20BD027 2 20 15 4 50 24.8 20.6 27 33 44 35 60 35 100 100 50 – – M-F8E-C32 -CMN-4000
20BD034 2 25 20 4 50 31.2 25.9 34 40.5 54 40 70 40 125 125 50 – – M-F8E-C45 -CMN-4000
20BD040 3 30 25 4 50 36.7 30.5 40 51 68 50 90 50 150 150 50 – – M-F8E-C45 -CMN-4000
20BD052 3 40 30 4 50 47.7 39.7 52 60 80 60 110 60 200 200 70 – – – -CMN-6300
20BD065 3 50 40 4 50 59.6 49.6 65 78 104 80 125 80 250 250 100 – – – -CMN-9000
20BD077 4 60 – 4 50 72.3 60.1 77 85 116 100 170 100 300 300 100 – – – -CMN-9000
– 50 4 50 59.6 49.6 65 98 130 80 125 80 250 250 100 – – – -CMN-9000
20BD096 5 75 – 4 50 90.1 74.9 96 106 144 125 200 125 350 350 125 – – – –
– 60 4 50 72.3 60.1 77 116 154 100 170 100 300 300 100 – – – -CMN-9000
20BD125 5 100 – 4 50 117 97.6 125 138 163 150 250 150 500 375 150 – – – –
– 75 4 50 90.1 74.9 96 144 168 125 200 125 350 350 125 – – – –
20BD156 6 125 – 4 50 147 122 156 172 234 200 350 200 600 450 250 – – – –
– 100 4 50 131 109 125 188 250 175 250 175 500 375 250 – – – –
20BD180 6 150 – 4 50 169 141 180 198 270 225 400 225 600 500 250 – – – –
– 125 4 50 147 122 156 234 312 200 350 200 600 450 250 – – – –
20BD248 6 200 – 2 40 233 194 248 273 372 300 550 300 700 700 400 – – – –
– 150 2 40 169 141 180 270 360 225 400 225 600 500 250 – – – –

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
