PowerFlex 700 Dimensions 1-15
Figure 1.9 PowerFlex 700 Frame 5
Dimensions are in millimeters and (inches).
Frame
(1)
(1)
Refer to Ta ble 1. B for frame information.
A (Max.) BC (Max.) DE
Approx. Weight
(3)
kg (lbs.)
(3)
Weights include HIM and Standard I/O.
Drive
Drive &
Packaging
5 308.9 (12.16) 644.5 (25.37)
(2)
(2)
When using the supplied junction box (100 HP drives Only), add an additional 45.1 mm (1.78 in.) to this
dimension.
275.4 (10.84) 225.0 (8.86) 625.0 (24.61) 37.19 (82.0) 42.18 (93.0)
HOT surfaces can cause severe burns
CAUTION
E
12.5
(0.49)
6.5 (0.26)
B
D
A
259.1 (10.20)
Detail
15.0 (0.59)
6.5 (0.26)
37.6 (1.48)
C
Lifting Holes - 4 Places
12.7 (0.50) Dia.
