Allen-Bradley PowerFlex 70 Reference Manual

Selecting An External Resistor 4-9
Table 4.B Resistor Selection – 480V AC Drives
Ohms Watts
Watt
Seconds
Catalog
Number
615 915 13302 440-1
615 605 13615 445-1
615 602 13302 440-1A
615 404 4225 445-1A
615 242 4225 442-1
615 180 4225 442-1A
439 1281 24647 440-2
439 848 9389 440-2A
439 847 11267 445-2
439 568 2973 445-2A
439 339 2973 442-2
439 254 2973 442-2A
360 86 17000 AKR2360P500
342 1645 36306 440-3
342 1096 22534 440-3A
342 1088 23473 445-3
342 734 14397 445-3A
342 435 3677 442-3
342 329 3677 442-3A
237 2373 61422 440-4
237 1577 39748 440-4A
237 1570 38496 445-4
237 1057 25351 445-4A
237 628 15649 442-4
237 473 5321 442-4A
181 3108 77775 440-5
181 2068 77853 440-5A
181 2055 77853 445-5
181 1385 30985 445-5A
181 822 19248 442-5
181 620 19248 442-5A
128 4395 138024 440-6
128 2912 82626 440-6A
128 2906 86382 445-6
128 1951 55397 445-6A
128 1162 32863 442-6
128 874 22065 442-6A
120 260 52000 AKR2120P1K2
117 3000 20800 T117R3K0
117 2700 14300 T117R2K7
117 2100 18600 T117R2K1
117 1500 15800 T117R1K5
117 1200 12500 T117R1K2
117 900 10600 T117R900W
117 600 10100 T117R600W
117 300 7950 T117R300W
97 4200 19100 T97R4K2
97 3600 22400 T97R3K6
97 3000 16800 T97R3K0
97 2700 19100 T97R2K7
97 2100 15400 T97R2K1
97 1500 20800 T97R1K5
97 1200 16500 T97R1K2
97 900 13800 T97R900W
97 600 13400 T97R600W
97 300 10300 T97R300W
81 6944 221276 440-7
81 4629 221432 440-7A
81 4592 224640 445-7
81 3102 55319 445-7A
81 1837 55084 442-7
81 1389 34975 442-7A
80 9300 230000 T80R9K3
80 9000 209000 T80R9K0
80 5700 29400 T80R5K7
80 4500 23300 T80R4K5
80 4200 25100 T80R4K2
80 3600 18500 T80R3K6
80 3000 22100 T80R3K0
80 2700 24600 T80R2K7
80 2100 19100 T80R2K1
80 1500 17500 T80R1K5
80 1200 13700 T80R1K2
80 900 18500 T80R900W
80 600 10900 T80R600W
80 300 8530 T80R300W
77 9300 230000 T77R9K3
77 9000 209000 T77R9K0
77 5700 28700 T77R5K7
77 4500 22400 T77R4K5
77 4200 24200 T77R4K2
77 3600 28100 T77R3K6
77 3000 21300 T77R3K0
77 2700 23800 T77R2K7
77 2100 19100 T77R2K1
77 1500 16400 T77R1K5
77 1200 20800 T77R1K2
77 900 17900 T77R900W
Ohms Watts
Watt
Seconds
Catalog
Number

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
