Allen-Bradley PowerFlex 70 Reference Manual

4-10 Selecting An External Resistor
77 600 10600 T77R600W
77 300 8210 T77R300W
60 11000 448000 T60R11K0
60 6900 164000 T60R6K9
60 4500 28000 T60R4K5
60 3600 22000 T60R3K6
60 2700 18500 T60R2K7
60 1500 20800 T60R1K5
60 1200 16400 T60R1K2
60 900 13700 T60R900W
60 600 13000 T60R600W
60 520 104000 (2)
AKR2120P1K2
60 300 10300 T60R300W
56 10045 388094 440-8
56 6702 245375 440-8A
56 6642 245375 445-8
56 4490 245062 445-8A
56 2657 154455 442-8
56 2010 61344 442-8A
48 20400 716000 T48R20K4
48 19100 656000 T48R19K1
48 12600 359000 T48R12K6
48 6600 131000 T48R6K6
48 5670 131000 T48R5K67
48 4200 23800 T48R4K2
48 3600 28000 T48R3K6
48 3000 21100 T48R3K0
48 2700 23300 T48R2K7
48 1500 16600 T48R1K5
48 1200 20800 T48R1K2
48 900 17500 T48R900W
48 600 16500 T48R600W
48 300 13100 T48R300W
45 19100 656000 T45R19K1
45 12600 359000 T45R12K6
45 6000 125000 T45R6K0
45 3600 26600 T45R3K6
45 3000 19800 T45R3K0
45 2700 22000 T45R2K7
45 2100 28100 T45R2K1
45 1500 24900 T45R1K5
45 1200 19100 T45R1K2
45 600 15800 T45R600W
45 300 12300 T45R300W
Ohms Watts
Watt
Seconds
Catalog
Number
44 12784 369388 440-9
44 8537 302807 440-9A
44 8454 305624 445-9
44 5720 184031 445-9A
44 3381 190604 442-9
44 2561 121670 442-9A
40 22000 1202000 T40R22K0
40 19000 568000 T40R19K0
40 17000 574000 T40R17K0
40 16000 521000 T40R16K0
40 11000 333000 T40R11K0
40 10000 309000 T40R10K0
40 4000 105000 T40R4K0
40 1800 18500 T40R1K8
40 1200 17300 T40R1K2
40 900 14300 T40R900W
40 300 10900 T40R300W
34 26000 1591000 T34R26K0
34 19000 1048000 T34R19K0
34 18000 1017000 T34R18K0
34 17000 990000 T34R17K0
34 15000 456000 T34R15K0
34 13000 456000 T34R13K0
34 9000 285000 T34R9K0
34 8000 262000 T34R8K0
34 4000 98600 T34R4K0
34 3600 93000 T34R3K6
34 2400 30100 T34R2K4
34 1800 25100 T34R1K8
34 900 19100 T34R900W
34 300 14700 T34R300W
32 28000 2304000 T32R28K0
32 26000 1591000 T32R26K0
32 18000 1017000 T32R18K0
32 17100 931000 T32R17K1
32 12700 410000 T32R12K7
32 8420 246000 T32R8K42
32 4500 105000 T32R4K5
32 4000 83300 T32R4K0
32 2700 25200 T32R2K7
32 2100 20200 T32R2K1
32 1500 28100 T32R1K5
32 900 19100 T32R900W
32 600 17500 T32R600W
32 300 13800 T32R300W
Ohms Watts
Watt
Seconds
Catalog
Number
480V AC Drives Continued

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
