Allen-Bradley PowerFlex 70 Reference Manual

Selecting An External Resistor 4-13
Table 4.C Resistor Selection – 600V AC Drives
Ohms Watts
Watt
Seconds
Catalog
Number
956 915 6260 550-1
956 605 6260 555-1
956 597 6260 550-1A
956 400 6260 555-1A
956 242 4225 552-1
956 179 4225 552-1A
695 1258 15258 550-2
695 832 7981 555-2
695 825 7981 550-2A
695 553 7981 555-2A
695 333 4929 552-2
695 248 4929 552-2A
546 1601 36619 550-3
546 1059 23004 555-3
546 1055 23004 550-3A
546 707 12050 555-3A
546 424 12050 552-3
546 316 5634 552-3A
364 2402 39514 550-4
364 1590 38496 550-4A
364 1588 38496 555-4
364 1065 24412 555-4A
364 635 15336 552-4
364 477 3990 552-4A
360 86 17000 AKR2360P500
283 3089 76680 550-5
283 2048 47338 550-5A
283 2043 48120 555-5
283 1372 30046 555-5A
283 817 19092 552-5
283 614 19092 552-5A
196 4460 130669 550-6
196 2965 83096 550-6A
196 2950 83096 555-6
196 1987 53519 555-6A
196 1180 33567 552-6
196 890 20970 552-6A
125 6994 212513 550-7
125 4625 208131 555-7
125 4620 208131 550-7A
125 3095 130903 555-7A
125 1850 51954 552-7
125 1386 32863 552-7A
120 260 52000 AKR2120P1K2
117 3000 20800 T117R3K0
117 2700 14300 T117R2K7
117 2100 18600 T117R2K1
117 1500 15800 T117R1K5
117 1200 12500 T117R1K2
117 900 10600 T117R900W
117 600 10100 T117R600W
117 300 7950 T117R300W
97 4200 19100 T97R4K2
97 3600 22400 T97R3K6
97 3000 16800 T97R3K0
97 2700 19100 T97R2K7
97 2100 15400 T97R2K1
97 1500 20800 T97R1K5
97 1200 16500 T97R1K2
97 900 13800 T97R900W
97 600 13400 T97R600W
97 300 10300 T97R300W
85 10285 361490 550-8
85 6854 231135 550-8A
85 6801 231135 555-8
85 4592 233795 555-8A
85 2720 92016 552-8
85 2056 57588 552-8A
80 9300 230000 T80R9K3
80 9000 209000 T80R9K0
80 5700 29400 T80R5K7
80 4500 23300 T80R4K5
80 4200 25100 T80R4K2
80 3600 18500 T80R3K6
80 3000 22100 T80R3K0
80 2700 24600 T80R2K7
80 2100 19100 T80R2K1
80 1500 17500 T80R1K5
80 1200 13700 T80R1K2
80 900 18500 T80R900W
80 600 10900 T80R600W
80 300 8530 T80R300W
77 9300 230000 T77R9K3
77 9000 209000 T77R9K0
77 5700 28700 T77R5K7
77 4500 22400 T77R4K5
77 4200 24200 T77R4K2
77 3600 28100 T77R3K6
Ohms Watts
Watt
Seconds
Catalog
Number

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
