Allen-Bradley PowerFlex 70 Reference Manual

Selecting An External Resistor 4-15
32 18000 1017000 T32R18K0
32 17100 931000 T32R17K1
32 12700 410000 T32R12K7
32 8420 246000 T32R8K42
32 4500 105000 T32R4K5
32 4000 83300 T32R4K0
32 2700 25200 T32R2K7
32 2100 20200 T32R2K1
32 1500 28100 T32R1K5
32 900 19100 T32R900W
32 600 17500 T32R600W
32 300 13800 T32R300W
28 30492 2138364 550-12
28 20646 1033301 555-12
28 20321 1100930 550-12A
28 13615 359925 555-12A
28 8258 237463 552-12
28 6096 299521 552-12A
27 27400 2075000 T27R27K4
27 21600 1346000 T27R21K6
27 15000 931000 T27R15K0
27 11500 391000 T27R11K5
27 8420 358000 T27R8K42
27 3300 73900 T27R3K3
27 2100 27300 T27R2K1
27 1500 23700 T27R1K5
27 1200 18800 T27R1K2
27 900 24900 T27R900W
27 600 15400 T27R600W
27 300 18500 T27R300W
25 8420 328000 T25R8K42
25 3900 190000 T25R3K9
25 3300 73900 T25R3K3
25 1500 22000 T25R1K5
25 1200 27700 T25R1K2
25 900 23000 T25R900W
25 600 14300 T25R600W
25 300 17200 T25R300W
24 36710 844315 550-13
24 24468 1871068 550-13A
24 24086 1173670 555-13
24 16393 533797 555-13A
24 9635 299938 552-13
24 7340 211079 552-13A
23 10200 310000 T23R10K2
Ohms Watts
Watt
Seconds
Catalog
Number
23 7490 328000 T23R7K49
23 6310 179000 T23R6K31
23 2100 23100 T23R2K1
23 1500 20200 T23R1K5
23 900 21300 T23R900W
23 600 20800 T23R600W
23 300 15800 T23R300W
20 34600 1148000 T20R34K6
20 28400 1066000 T20R28K4
20 20600 1602000 T20R20K6
20 15200 924000 T20R15K2
20 10700 582000 T20R10K7
20 8920 267000 T20R8K92
20 5940 260000 T20R5K94
20 1500 28000 T20R1K5
20 900 18500 T20R900W
20 600 17300 T20R600W
20 300 13700 T20R300W
19 47709 5953399 550-14
19 31965 2913365 555-14
19 31798 3029900 550-14A
19 21305 1514674 555-14A
19 12170 410613 552-14
19 9540 410613 552-14A
15 60579 7591398 550-15
15 40587 1313963 555-15
15 40388 1300276 550-15A
15 27060 719851 555-15A
15 18173 1158280 552-15
15 12112 550465 552-15A
15 11400 734000 T15R11K4
15 8570 466000 T15R8K57
15 6160 232000 T15R6K16
15 4210 143000 T15R4K21
15 1500 38800 T15R1K5
15 900 22000 T15R900W
15 600 20800 T15R600W
15 300 16400 T15R300W
14 12700 1038000 T14R12K7
14 11400 734000 T14R11K4
14 6160 232000 T14R6K16
14 1800 27800 T14R1K8
14 1200 24500 T14R1K2
14 900 20700 T14R900W
14 600 19400 T14R600W
Ohms Watts
Watt
Seconds
Catalog
Number
600V AC Drives Continued

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
