Analog Outputs 2-25
Example
Analog Output 1 set for 0-10V DC at 0-100% Commanded Torque.
Setup
• [Analog Out1 Sel], parameter 342 = 14 “Commanded Torque”
• [Analog Out1 Hi], parameter 343 = 10.000 Volts
• [Analog Out1 Lo], parameter 344 = 0.000 Volts
• [Anlg Out1 Scale], parameter 354 = 100.0
If [Analog Out1 Lo] = –10.000 Volts the output will be –10.0 to +10.0V DC
for –100% to +100% Commanded Torque.
If [Anlg Out1 Scale] = 0.0, the default scaling listed in [Analog Out1 Sel]
will be used. This would be 0-1.25V DC for 0-100% Torque or 0-800% for
0-10V DC.
Scale Block Analog Output
Selects scaled analog output relative to the Scale Block value. Values not in
the [Analog OutX Sel] parameter list can be used to drive the analog
outputs. When using the Scale Block select, the Scale block Out Hi and Out
Lo parameters are not used.
Example
Analog Output 2 set for 0-10V DC for Heat Sink Temp 0-100 Degrees C.
using Scale Block 1.
Setup
• Link [Scale1 In Value], parameter 476 to [Testpoint 1 Data], param. 235
• [Testpoint 1 Sel], parameter 234 = 2 “Heat Sink Temp”
• [Analog Out2 Sel], parameter 345 = 20 “Scale Block 1”
• [Analog Out2 Hi], parameter 346 = 10.000 Volts
• [Analog Out2 Lo], parameter 347 = 0.000 Volts
• [Scale1 In Hi], parameter 477 = 100
• [Scale1 In Lo], parameter 478 = 0
INPUTS & OUTPUTS
Analog Outputs
354
355
[Anlg Out1 Scale]
[Anlg Out2 Scale]
Sets the high value for the range of
analog out scale. Entering 0.0 will disable
this scale and max scale will be used.
Example: If [Analog Out Sel] =
“Commanded Trq,” a value of 150 =
150% scale in place of the default 800%.
Default:
Min/Max:
Units:
0.0
[Analog Out1 Sel]
0.01
Vector v3
Vector v3
477
In Lo
In Hi
In Hi
Out Lo
Out
Out Hi
235
Testpoint 1 Data
476
478
479
481
480
Scale 1
Link
To Next Page
