Publication 2711-UM014B-EN-P
Installing the PV300 Micro Terminal 6-5
7. Alternately tighten the self-locking nuts until the terminal is held
firmly against the panel. Tighten the nuts to a torque of 10
inch-pounds. Do not overtighten.
ATTENTION
!
Mounting nuts must be tightened to a torque of 10
inch-pounds to provide a proper seal and to prevent
potential damage to the terminal. Allen-Bradley
assumes no responsibility for water or chemical
damage to the terminal or other equipment within
the enclosure because of improper installation.
Self-Locking Nuts
(4 used, 6 provided)
To Next Page
