Allen-Bradley PV550

Publication 2711-UM014B-EN-P
1-4 Terminal Overview
PanelView 600 Color Terminals
1
Add L1 to the end of the catalog number for 24V dc power.
Operator
Input
Communication Port
Printer Port
RS-232
Catalog
Number
1
RIO DH-485 RS-232
(DH-485)
DH+ DeviceNet ControlNet RS-232
(DF1)
Ethernet
Touch Screen
and Keypad
x x 2711-B6C1
x 2711-B6C2
x x 2711-B6C3
x 2711-B6C5
xx2711-B6C8
xx2711-B6C9
xx2711-B6C10
xx2711-B6C15
xx2711-B6C16
xx2711-B6C20
Keypad
x x 2711-K6C1
x 2711-K6C2
x x 2711-K6C3
x 2711-K6C5
xx2711-K6C8
xx2711-K6C9
xx2711-K6C10
xx2711-K6C15
xx2711-K6C16
xx2711-K6C20
Touch
Screen
(24V dc only)
x x 2711-T6C1L1
x 2711-T6C2L1
x x 2711-T6C3L1
x 2711-T6C5L1
xx2711-T6C8L1
xx2711-T6C9L1
xx2711-T6C10L1
xx2711-T6C15L1
xx2711-T6C16L1
xx2711-T6C20L1
