Terminal Overview 1-19
# Feature Description
1 Function Keys (F1 - F10) Use the function keys on keypad terminals to initiate
functions on the terminal display. These keys may have
custom legends.
On the keypad & touch screen terminals, you can initiate
functions using the function keys and/or touch screen
objects.
2Cursor Keys Use the cursor keys to move the cursor in displayed lists, to
select a numeric entry object, or to enter configuration
mode.
3 Numeric Entry Keys 0-9 Enters numeric values.
. Enters a decimal point.
- Enters a negative value.
← Clears entered digits or cancels the scratchpad.
↵ Stores an entered value.
4 Keypad Terminal Display On keypad terminals, initiate the function of a displayed
object, such as an ON or OFF push button, by pressing a
function key (F1 - F10).
5 Touch Screen
Terminal Display
On keypad & touch screen terminals, initiate the function of
a displayed object, such as an ON or OFF push button, by
touching the screen object. Each interactive screen object
occupies one or more of 128 cells.
On touch screen & keypad terminals, you can initiate
functions, using the function keys and/or touch screen
objects.
6 Touch Cells
(Touch Screen terminal)
The 128 touch cells (16 columns x 8 rows) let you initiate
functions by touching the screen. Interactive screen objects
are aligned with touch cells when the application is created.
