Allen-Bradley PV550

Publication 2711-UM014B-EN-P
Terminal Overview 1-37
Antiglare Overlay
Self-adhesive filters minimize the reflection of terminal displays.
DH-485 Operating and Programming Cables
Catalog No. 300M 300 550 600 900 1000 1400
2711-NV4 (Keypad)
x
2711-NV4T (Touch Screen Terminals)
xx
2711-NV3K (Keypad)
x
2711-NV3T (Touch Screen Terminals)
x
2711-NV5 (Keypad)
x
2711-NV7K (Keypad Terminals)
x
2711-NV7T (Touch Screen Terminals)
x
2711-NV6K (Keypad Terminals)
x
2711-NV6T (Touch Screen Terminals)
x
2711-NV8 (Keypad Terminals)
x
Catalog No. Description
1747-PIC Personal Computer Interface Converter converts RS-232 signals to/from RS-485
signals. Use to transfer applications between a DH-485 terminal and a computer.
1747-C10 1.83 meter (6 foot) cable connects a DH-485 terminal to an SLC or DH-485 network.
1747-C11 0.30 meter (1 foot) cable connects a DH-485 terminal to an SLC or DH-485 network.
1747-C20 6.1 meter (20 foot) cable connects a DH-485 terminal to an SLC or DH-485 network.
1747-CP3 45 cm (17.7 inch) cable connects an RS-232 terminal to an AIC+ (Port1) through a null
modem adapter.
1761-CBL-AP00 45 cm (17.7 inch) cable connects an RS-232 terminal to an AIC+ (Port2) through a null
modem adapter.
1761-CBL-AC00 3 meter (9.8 foot) cable connects an RS-232 terminal to an AIC+ (Port1) through a null
modem adapter.
1761-CBL-AS03 3 meter (9.8 foot) cable connects a DH-485 terminal to an AIC+ (Port3).
1761-CBL-AS09 9.9 meter (29.5 foot) cable connects a DH-485 terminal to an AIC+ (Port3).
1761-CBL-AM00 45 cm (17.7 inch) cable with 2 mini DIN, right angle connectors.
1761-CBL-HM02 2 meter (6.5 foot) cable with 2 mini DIN, right angle connectors.
2711-CBL-HM05 5 meter runtime cable with 2 mini DIN, right angle connectors.
2711-CBL-HM10 10 meter runtime cable with 2 mini DIN, right angle connectors.
1761-CBL-PM00 45 cm (17.7 inch) cable connects an RS-232 terminal to an AIC+ (Port2) through a null
modem adapter.
1761-CBL-PM02 2 meter (6.5 foot) cable connects an RS-232 terminal to an AIC+ (Port2) through a null
modem adapter.
2711-CBL-PM05 5 meter programming cable with a D-shell and mini DIN connector.
2711-CBL-PM10 10 meter programming cable with a D-shell and mini DIN connector.
