4.8 - Model 9910 Pump Assembly,
Parts List (9910-D30GRGI)
ITEM PART # DESCRIPTION QTY
1 9910-629011 Pump Body with Bolts 1
2 9910-620101 Assembly, Right Head (DX) 1
3 9910-620102 Assembly, Left Head (SX) 1
4 9910-621430 Fastener, Bolt, M12 x 55mm 8
5
1
9910-620085 Diaphragm, Desmopan (standard) 2
9910-620080 Diaphragm, Buna-N (optional) 2
6 9910-620120 Piston 2
7 9910-620140 Connecting Rod 2
8 9910-620110 Sleeve 2
9 9910-580470 Retainer Ring 2
10 9910-380300 Connection Rod Pin 2
11 9910-380080 Ring Pin 4
12 9910-160230 Piston Ring 2
14 9910-1040180 Retaining Washer 2
15 9910-580360 Fastener, Bolt, for Diaphragm 2
16 9910-180150 Fastener, Nut 2
18
1,2,3
9910-620030 O-Ring 4
19
2
9910-1409050 Complete Valve Assembly 4
20 9910-111120 Retaining Ring 2
21 9910-620020 Cover 1
22
3
9910-620291 O-Ring 1
23 9910-620291 Retaining Ring 1
24 9910-620190 Bearing 1
25 9910-850850 Fastener, Bolt, M6 x 30mm 2
26 9910-550331 Washer 2
28
3
9910-180101 O-Ring 2
29 9910-550030 Oil Sight Glass 1
30
3
9910-550040 O-Ring 1
31 9910-550056 Oil Sight Glass Cap 1
32 9910-620160 Spacer 1
33 9910-550060 Roller Bearing 1
34 9910-620130 Seal 1
35 9910-620330 Retaining Ring 1
36 9910-620170 Crankshaft 1
37 9910-620150 Suction Manifold 1
38 9910-550340 Threaded Adapter 1
39
3
9910-550350 O-Ring 2
40 9910-550242 Ring Nut 1
41 9910-550370 Hose Barb 1
42
3
9910-390060 O-Ring 4
Continued On Next Page
