ITEM PART # DESCRIPTION QTY
44 9910-621780 Fastener, Bolt, M8 x 40mm 8
45 9910-629211 Upper Air Chamber 1
46
1
9910-550190 Accumulator, Diaphragm, Buna-N 1
47 9910-622070 Lower Air Chamber Body 1
49
3
9910-650542 O-Ring 1
50 9910-180020 Air Valve 1
51
3
9910-390290 O-Ring 1
52 9910-620680 Key (VP-A Model) 1
53
9910-620172 Thru-Shaft, 20mm Diameter (AP Version) 1
9910-620174 Thru-Shaft, 3/4” Diameter (AP Version) 1
58 9910-620630 Seal 1
59 9910-620021 Cover 1
60 9910-650660 Diaphragm Holder 1
61 9910-650970 Suction Diaphragm 1
62 9910-650690 Clamp 1
63 9910-1500350 PTO Shield 1
64 9910-820670 Fastener, Bolt, M10 x 16mm 4
65 9910-620190 Bearing 1
66 2406-0023 Drain Plug, Oil 1
67
3
9910-740290 O-Ring 1
68 9910-620930 Spacer 1
69 9910-620940 Spacer 1
70 9910-380230 Bearing 1
74 9910-390270 Fastener, Nut 2
75 9910-450145 Flange 1
76 9910-110130 Fitting, Hose Barb, 1/2” 1
4.8 - Model 9910 Pump Assembly, Parts
List, continued (9910-D30GRGI)
Continued From Previous Page
FASTENER TORQUE REQUIREMENTS
ITEM DESCRIPTION
TIGHTENING TORQUE
In. Lbs. Nm
4 Fastener, Bolt, M12 x 55mm 393.7 44.1
15 Fastener, Bolt, for Diaphragm 262.5 29.4
16 Fastener, Nut 350.0 39.2
25 Fastener, Bolt, M6 x 30mm 87.5 9.8
44 Fastener, Bolt, M8 x 40mm 175.0 19.6
64 Fastener, Bolt, M10 x 16mm 87.5 9.8
74 Fastener, Nut 175.0 19.6
*3
9910-KIT1916
O-Ring Kit
ITEM QTY.
18 4
22 1
18 2
30 1
39 2
42 4
49 1
51 1
67 1
*2
9910-KIT1917
Valve Kit
ITEM QTY.
18 4
19 4
*1
9910-KIT1724
Diaphragm Kit
Desmopan
ITEM QTY.
5 2
18 4
46 1
SECTION 4
PARTS
