28 M411433
Section 5 Service Procedures
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 1
SUPPORT
ROD
ACCESS
PANEL
CONTROL PANEL
ATTACHING SCREWS
PUSH-TO-START
SWITCH
SCREWS
T056SE3D
CONTROL
PANEL BRACKET
PUSH-TO-START
SWITCH ASSEMBLY
CONTROL PANEL
BRACKETS
WIRE HARNESS
PLUG
TERMINAL
BOARD
T057SE3A
