Electrical Requirements
92
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 70458301ENR7
Non-reversing Reversing Breaker Rating Wire Size AWG
(mm
2
)
380V/50Hz/3ph** L1, L2, L3, and
ground
19.4 19.4 25A* – 3 pole 10 (6)
400-415V/50Hz/3ph** L1, L2, L3, and
ground
17.8 17.8 25A* – 3 pole 10 (6)
* 3 Phase machines should not have fuses, breakers only.
** These serial plate voltages are only options available on the 30 series electric models.
Table 20
21 kW Classic Line T30 Series Electric Models
Recommended CircuitSerial Plate Voltage Terminal Block
Connections Required
Serial Plate Amps
Breaker Rating Wire Size AWG (mm
2
)
200-208V/60Hz/3ph* L1, L2, L3, and ground 62** 80A – 3 pole 4 (25)
200V/50Hz/3ph* L1, L2, L3, and ground 60** 80A – 3 pole 4 (25)
230-240V/50Hz/3ph* L1, L2, L3, and ground 55** 70A – 3 pole 4 (25)
240V/60Hz/3ph* L1, L2, L3, and ground 54** 70A – 3 pole 4 (25)
380V/50 or 60Hz/3ph* L1, L2, L3, and ground 33** 45A – 3 pole 8 (10)
400-415V/50Hz/3ph* L1, L2, L3, and ground 31** 40A – 3 pole 8 (10)
440V/60Hz/3ph L1, L2, L3, and ground 29** 40A – 3 pole 8 (10)
460-480V/60Hz/3ph L1, L2, L3, and ground 27** 35A – 3 pole 8 (10)
* These serial plate voltages are only options available on the T30 electric models. Current (Amp) is for one pocket only.
** Per heater on T30 electric models, each has two heaters.
Table 21
