Electrical Requirements
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 93
12 kW Eco Line T30 Series Electric Models
Recommended CircuitSerial Plate Voltage Terminal Block
Connections Required
Serial Plate Amps
Breaker Rating Wire Size AWG (mm
2
)
380V/50Hz/3ph* L1, L2, L3, and ground 39** 50A – 3 pole 6 (16)
400-415V/50Hz/3ph* L1, L2, L3, and ground 36** 45A – 3 pole 8 (10)
* These serial plate voltages are only options available on the T30 electric models. Current (Amp) is for one pocket only.
** Per heater on T30 electric models, each has two heaters.
Table 22
24 kW Classic Line 035 Series Electric Models
Serial Plate Amps Recommended CircuitSerial Plate
Voltage
Terminal Block
Connections
Required
Nonreversing Reversing Breaker Rating Wire Size AWG
(mm
2
)
208V/60Hz/1ph L1, L2, Neutral,
and ground
122 N/A 175A – 2 pole 2/0 (70)
240V/60Hz/1ph L1, L2, Neutral,
and ground
107 N/A 150A – 2 pole 1/0 (50)
200V/60Hz/1ph L1, Neutral, and
ground
122 N/A 175A – 1 pole 2/0 (70)
200V/50Hz/1ph L1, Neutral, and
ground
119 N/A 150A – 1 pole 1/0 (50)
230-240V/50Hz/1ph L1, Neutral, and
ground
108 N/A 150A – 1 pole 1/0 (50)
200-208V/60Hz/3ph L1, L2, L3, and
ground
71 71 90A* – 3 pole 3 (26.7)
200V/50Hz/3ph L1, L2, L3, and
ground
65 65 90A* – 3 pole 3 (26.7)
