34
Appendix A
Technical Specifications
Physical Specifications
Dimensions: (W x D x H)
250 mm x 117 mm x 36 mm
(9.83 in x 4.60 in x 1.42 in)
Weight: 0.77 kg (1.7 lbs)
Environmental Specifications
Operating Temperature: 0° C to 40° C (32° F to 104° F)
Storage Temperature: -25° C to 70° C (-13° F to 158° F)
Operating Humidity: 5% to 90% non-condensing
Storage Humidity: 5% to 95% non-condensing
Operating Altitude Range: Up to 10,000 feet (3,048 meters)
MTBF: 250,000 hours
Power Specifications
Power Consumption: 9 watts maximum
AC Input Electrical Ratings: AC 100~240 VAC
Frequency: 50/60 Hz
Rated Output: 3.3V / 4A
