AT-FS716L Fast Ethernet Switch Installation Guide
13
Key Features
The AT-FS716L switch has the following key features:
Sixteen 10/100 Mbps (10Base-T / 100Base-TX) twisted pair ports
with RJ-45 connectors
System and port LEDs
Auto MDI/MDI-X on all 10/100 Mbps twisted pair ports
Support half- or full-duplex mode on all 10/100 Mbps twisted pair ports
Auto-Negotiation (IEEE 802.3u-compliant)
Flow control (IEEE 802.3x-compliant)
Store-and-forward packet forwarding
Storage up to 8K MAC addresses
For use on a desktop, on a wall, or in a rack
RoHS Compliant
Standards
IEEE 802.3 – Ethernet
IEEE 802.3i – 10Base-T
IEEE 802.3u – 100Base-TX
IEEE 802.3x – Flow Control, Symmetric and Asymmetric
