•ActivatesaspecialfunctionprogrammedintotheTCM,whichistypically

analternateECONOMYorPERFORMANCEshiftschedule.

•TogglestothenextDTCwhileinDTCdisplaymode.

•Clears(erases)activeandinactiveDTCsfromTCMmemory.

NOTE:DTCscannotbeclearedindividually.AllactiveDTCsclear

rst,followedbytheinactive(historic)DTCs,providedtheMODE

buttonispressedlongenoughwhileintheDTCdisplaymode.Refer

to6.0DIAGNOSTICSforinformationandtheprocedureonreading

andclearing(erasing)DTCs.

AMODEdisplayislocatedneartheMODEbuttontoidentifythepurpose

associatedwiththeMODEbuttonselection.RefertoFigure7–1forthe

locationoftheMODEbuttonandMODEdisplayonabump-shiftlever

selector.RefertoFigure7–2forthelocationoftheMODEbuttonandMODE

displayonapushbuttonshiftselector.

(1)–MODEButton

Figure7–1.MODEButtonandDisplayOnaBump-ShiftLeverSelector
