c) Launch the machine and run after the requirement
Battery System
Item
Description
Parameter
Remark
1
Nominal discharge power
50 kW / 100 kW
2
Energy storage capacity
According to the project
situation
Ambient temperature
is 30℃, measured at
DC side
3
Continuous discharge current
1C (continuous)
4
Direct voltage
250 ~ 520 V
5
Communication interface
RS485, CAN2.0
3.3.3.1 M48112-S
Figure 3-5 Battery appearance
Figure 3-6 Battery front cover
Battery interface definition:
No.
Description
No.
Description
1
Battery negative pole
5
Dip switch
2
Battery positive pole
6
COM port
3
Earthing point
7
Information label
