SPLIT with climate system and any addition
Klimatsystem
BT 1
RG10/
RE10
CP1
Erf. säker-
hetsutr.
FQ1
FL1
Överströmnings-
ventil
AMS 10-12
HBS 16
HEV 300/HEV 500
Extern tillsats
Climate system
Overflow valve
HM 8-12
SPLIT
L8 SPLIT /L12
SPLIT
RFV SPLIT/
RBE SPLIT
WWS 300 SPLIT/WWS 500 SPLIT
Required
safety devices
External additional
heat
Klimatsystem
BT 1
RG10/
RE10
CP1
Överströmnings-
ventil
HE 30
AMS 10-12
HBS 16
Climate system
Overflow valve
HM 8-12
SPLIT
L8 SPLIT /L12
SPLIT
RFV SPLIT/
RBE SPLIT
EHZK 90 SPLIT
NOTE
These are outline diagrams. Actual installations must
be planned according to applicable standards.
SPLIT30
For the Installer
Pipe installation
