L12 SPLITL8 SPLITOutdoor module
Twin RotaryCompressor
25–85 Hz (rps)20–81 Hz (rps)Speed, heating
20–80 Hz (rps)20–86 Hz (rps)Speed, cooling
4380 m
3
/h3000 m
3
/hMax fan flow (heating, nominal)
86 WFan rating
ReversingDefrosting
IntegratedIntegratedDrain pan heater
120 W100 W
4.15 MPa (41.5 bar)Breaking value high pressure
0.079 MPa (0.79 bar)Cut-out value low pressure (15 s)
845 mm750 mmHeight
970 mm780 mm (+67 mm valve
protection)
Width
370 mm (+ 80 mm with
foot rail)
340 mm (+ 110 mm with
foot rail)
Depth
74 kg60 kgWeight
Dark grayColour (two coats powder coating)
5-core 2.5 mm
2
Power and communication connection from indoor module
2.90 kg2.55 kgRefrigerant volume (R410A)
30 m*Max. length, refrigerant pipe, one way
Bottom / right-hand sideRight-hand sidePipe connection option
/ rear side
100 627 01100 626 01Part no.
WWS 500 SPLITWWS 300 SPLITEHZK 90 SPLITTank
9 kWImmersion heater Max 9 kW
4 (2, 4, 6, 9 kW)Number of power steps (power)
35–45 °C (factory setting 35 °C)Emergency mode thermostat
98 (-8) °CTemperature limiter (resetting differential).
0.25 MPa (2.5 bar)Safety valve, climate system
IP 21Enclosure class
500 l300 l30 lVolume, total
21 l14 l-Volume, hot water coil
Stainless steel (AISI316L/AISI316
DIN 1.4404/1.4401)
-Material, hot water coil
0.25 MPa (2.5 bar)Max pressure, vessel
1.0 MPa (10 bar)Max pressure, hot water coil
≤ EU directive no. 98/83/EFThe water quality, domestic hot water and climate system
65 °CMax operating temperature, tank
5–35 °C, max relative humidity 95 %Ambient temperature, tank
143 W82 W-Idle loss according to EN255-3.
1” ext. thread-Connection, domestic water
1” int. thread-Connection, docking
28 mm compres-
sion fitting
1” ext. threadConnection HM 8-12 SPLIT
1740+(20-55)
mm
1900+(20-45)
mm
385 mmHeight
1900 mm2080 mm-Required ceiling height
760 mm600 mm596 mmWidth
93SPLIT
Miscellaneous
Technical specifications
