Alpha-InnoTec L8 SPLIT - Technical Specifications

Technical specifications
3 x 400 V1 x 230 VSPLIT
-20 – +43 °CWorking range during heating with compressor (ambient temperature)
+15 – +43 °CWorking range during cooling (ambient temperature)
65 °CMax temperature flow line
58 °CMax temperature flow line, only compressor
65 °CMax temperature return line
25 °CMin temperature flow line during heating with compressor and continuous
operation
25 °CMaximum temperature supply during cooling and continuous operation
25 A50 AMax. current
25 A50 ARecommended fuse rating
5 AStarting current
-15 % – +10 %Incoming supply, deviation
≤ EU directive no. 98/83/EFThe water quality, domestic hot water and climate system
HM 8-12 SPLITIndoor module
3–45 W (variable speed)Circulation pump, output
73 kPa (external)Circulation pump, max available pressure
0.61 l/sCirculation pump, max flow
0.49 l/sCirculation pump, flow at 20 kPa external pressure drop
L8 SPLIT: 0.12 /0.38 l/sMin/max system flow, heating operation
L12 SPLIT: 0.15 /0.57 l/s
L8 SPLIT: 0.15 /0.38 l/sMin/max system flow, cooling operation
L12 SPLIT: 0.20 /0.57 l/s
L8 SPLIT: 0.19 l/sMin flow, climate system, at 100% circulation pump speed (defrost flow)
L12 SPLIT: 0.29 l/s
IP 21Enclosure class
4 l ±5 %Volume, total
0.25 MPa (2.5 bar)Max pressure, climate system
18 lExpansion vessel
4.5 MPaMax pressure, cooling system
≤ EU directive no. 98/83/EFWater quality, climate system
65 °CMax operating temperature
5–35 °C, max relative humidity95 %Ambient temperature
Compression ring 28 mmConnection, tank
1040/1140 mmHeight, without pipe/with pipe
510 mmWidth
360 mmDepth
68.5 kgWeight
230 V 1AC 50 Hz or 400 V 3NAC 50 HzElectrical connections
7 °CMin temperature flow line during cooling
150 818 01Part no.
*Depending on display language.
SPLIT92
