Alpha-InnoTec L8 SPLIT - Page 36

External additional heat
Gaspanna Olje-/pelletspanna
Solfångare
EP8
RM5
ALT 1
GAS V.
ALT 2
HQ
EB1
EM2
RM5
RM5
On/off
Frånluftsvärmepump
On/off
Vedpanna med ackumulator
CP1
CM5
GP31
GP32
EM1
FL1
GP12 GP12
RM
CP2
Extern styrning
Extern styrning
Solar panels Wood boiler with accumulator
Gas boiler Oil/pellet boiler
Solar panels
Accumulator
Wood-fired
boiler
Oil /
pellets
Gas
boiler.
On/Off
Exhaust air heat pump
On/Off
F120
Accumulator
ALT. 2
ALT. 1
External control
External control
Explanation
Pump station, limits low temperat-
ure
GP32Oil/Pellet boilerEM2Expansion vesselCM5
Particle filterHQSafety valveFL1Accumulator tankCP1
Non-return valveRM5Charge pumpGP12Immersion heaterEB1
Pump station, limits high temperat-
ure
GP31Wood-fired boilerEM1
SPLIT32
For the Installer
Pipe installation
