Menu 9.1.6 [S] Stop temp. cool high
Upper parameter for the heat pump's working range
during cooling. It stops above this outdoor air temperature.
The heat pump is permitted to start again when the out-
door air temperature decreases by two degrees below the
set value.
Setting range: 10 – 43 °C
Factory setting: 43 °C
Menu 9.1.7 [S] Time bet. starts
Minimum time interval in minutes between compressor
starts in the heat pump.
Setting range: 0 – 60 min
Factory setting: 0 min
Menu 9.1.8 [S] Min CompFreq act/set
Select the min compressor frequency here. Display of both
the current and the set.
L12 SPLITL8 SPLIT
20 – 80 Hz20 – 81 HzSetting range
20HzFactory setting
Menu 9.1.9 [S] Max CompFreq act/set
Select here the max limit for the compressor. Display of
the actual and set via the display.
L12 SPLITL8 SPLIT
25 – 85 Hz20 – 86 HzSetting range
85Hz86HzFactory setting
Menu 9.1.10 [S] OU current heat act/max
The phase current to L8 SPLIT/L12 SPLIT and the highest
permitted current that can be set during heating are
shown here.
L12 SPLITL8 SPLIT
7 – 177 – 16Setting range
15Factory setting
Menu 9.1.11 [S] OU cur. cool act/max
The phase current to L8 SPLIT/L12 SPLIT and the highest
permitted current that can be set during cooling are shown
here.
Setting range: 7 – 17
Factory setting: 15
L12 SPLITL8 SPLIT
7 – 177 – 15Setting range
1514Factory setting
Menu 9.1.12 [S] Tank defrost Temp.
If the system is colder than the set value defrosting occurs
connecting to HW. If HW is colder, the electrical addition
starts.
Setting range: 20 – 30 °C
Factory setting: 20 °C
Menu 9.1.13 [S] Return
Return to menu 9.1.0.
Menu 9.2.0 [S] Add. heat settings
Settings regarding additional heat and shunt in HM 8-12
SPLIT and any extra shunt can be made in the sub-menus
to this menu.
Menu 9.2.1 [S] DM start add. heat
The degree minute deficit that must be set before the ad-
ditional heat supply is activated is set here.
Setting range: -1000 – -30
Factory setting: -400
Menu 9.2.2 [S] Time factor
The time factor of the immersion heater since first start up
is shown here. The value is saved and is not reset even
when the boiler is switched off using the main power
switch.
Menu 9.2.6 [S] Shunt amplification
Applies to shunt 1 (QN11). E.g. 2 degrees difference and
2 in amplification gives 4 sec/min controlling the shunt.
Setting range: 0.1 – 5.0
Default value: 1.1
Menu 9.2.7 [S] Shunt amplification2
Applies to any shunt 2 (accessory required). E.g. 2 degrees
difference and 2 in amplification gives 4 sec/min con-
trolling the shunt. This function compensates for the speed
variation found on different shunt motors that may be in-
stalled.
Setting range: 0.1 – 5.0
Default value: 1.0
Menu 9.2.8 [S] Add. heat type
Select the type of addition to be used.
Setting range: Internal power 1, Ext. 1 step, Ext. Lin 3,
Ext. Bin 3
Default values: Internal power 1
Menu 9.2.9 [S] Return
Return to menu 9.2.0.
Menu 9.3.0 [S] Operating settings
Settings regarding accessories, additional heat operation,
floor drying and a return to the factory settings can be
made in the sub-menus to this menu.
Menu 9.3.1 [S] Max. boiler temp.
The setting selected on the EBV board (AA22) knob (R26)
is shown here.
Menu 9.3.2 [S] Logger
NOTE
Only for service work, special accessory required.
Select “On” here if logger is installed.
Setting range: Off, On
Default value: Off
SPLIT60
