List of components
High pressure pressostat63H1
Low pressure transmitterLPT
FanFM01
4-way valve20S
CompressorCM
Control boardPWB1
Inverter boardPWB2
Filter boardPWB3
Service valve, liquid sideQM35
Service valve, gas sideQM36
Expansion valve, heatingEEV-H
Expansion valve, coolingEEV-C
Terminal block, incoming supply and communicationTB
Serial number platePF3
Drain pan heaterDH
LEK
PF3
83SPLIT
Miscellaneous
Component positions
