Gerätebezeichnung
Heat pump type Brine/water ı Air/water ı Water/water • applicable ı — not applicable
Installation location Indoors ı Outdoors • applicable ı — not applicable
Conformity CE
Performance data Heating capacity/COP at
B0/W35 Standard point acc. to EN14511
2 compresssors
1 compresssor
kW ı …
kW ı …
B0/W45 Standard point acc. to EN14511
2 compresssors
1 compresssor
kW ı …
kW ı …
B0/W35 Standard point acc. to EN255
2 compresssors
1 compresssor
kW ı …
kW ı …
Limits of application Heating circuit °C
Heat source °C
Additional operating points …
Sound Sound level measured at distance of 1m around the device (in free field) dB(A)
Sound power level according to EN12102 dB
Heat source Volume flow: minimum flow rate ı nominal flow rate ı maximum flow rate l/h
Pressure loss heat pump ∆p (with cooling ∆pK) ı volume flow bar (bar) ı l/h
Free compression heat pump ∆p (with cooling ∆pK) ı volume flow bar (bar) ı l/h
Anti-freeze agent monoethylene glycol
minimum concentration ı frost proof down to % ı °C
Heating circuit Volume flow: minimum flow rate ı nominal flow rate ı maximum flow rate l/h
Pressure loss heat pump ∆p (with cooling ∆pK) ı volume flow bar (bar) ı l/h
Free compression heat pump ∆p (with cooling ∆pK) ı volume flow bar (bar) ı l/h
General unit data Dimensions (see dimensional drawing for the specified unit size) unit size
Total weight (including cooling) kg (kg)
Additional weight module 1 kg
Additional weight module 2 kg
Connections Heating circuit …
Heat source …
Refrigerant Refrigerant type ı Quantity … ı kg
Electric Voltage code ı all-pole circuit breaker heat pump *) … ı A
Voltage code ı circuit breaker control voltage *) … ı A
Voltage code ı circuit breaker electric heating element *) ı A
Heat Pump Effective power consumption in standard point B0/W35 according to EN14511: Power consumption ı current consumption ı cosφ kW ı A ı …
Maximum device current within the limits of application A
Starting current: direct ı with soft starter A ı A
Protection type IP
Output electric heating element 3 ı 2 ı 1 phase kW ı kW ı kW
Components Circulating pump heating circuit at nominal flow rate: Power consumption ı current consumption kW ı A
Circulating pump heat source at nominal flow rate: Power consumption ı current consumption kW ı A
Passive cooling function only for units with designator K: Cooling output at nominal volume flow (15 °C heat source, 25 °C heating water) kW
Safety equipment Safety component heating circuit ı Safety component heat source scope of delivery: • yes — no
Heating and heat pump regulator scope of delivery: • yes — no
Electronic soft starter integrated: • yes — no
Expansion vessels Heat source: Scope of delivery ı Volume ı Initial pressure • yes — no ı l ı bar
Heating circuit: Scope of delivery ı Volume ı Initial pressure • yes — no ı l ı bar
Overflow valve integrated: • yes — no
Vibration decouplers Heating circuit ı heat source scope of delivery: • yes — no
UK813196-c
*) comply with local regulations n.n. = not detectable
