53
The heating system is filled and pressure tested; the circulating pumps function properly.
q
No
q
Yes
The heat source system is completed, inspected and OK.
q
No
q
Yes
The heating circuit, heat source system and circulating pumps have been bled.
q
No
q
Yes
All electrical components are connected in accordance with the terminal diagram and applicable
local regulations.
q
No
q
Yes
All volume flows and water flow rates have been checked and are OK.
q
No
q
Yes
Checked on: .............................................................................
by: ............................................................................................... Signature: ........................................................................................
In Germany the following applies: send this general checklist along with the completed report for heat pump
systems to the factory customer service.
Outside of Germany the following applies: send this general checklist along with the completed report for heat pump
systems to the manufacturer‘s local service partner.
Sending the general checklist and the completion report also serves as a request for a technician authorized by the manufacturer to
commission your heat pump.
FOR PREPARATION OF THE COMPLETION REPORT FOR HEAT PUMP SYSTEMS
The general checklist is intended as an aid for the installation and assembly personnel. It makes no claim to be exhaustive.
Nevertheless, all items must be checked carefully for compliance.
Heat source air
Channels closed and sealed
q
Yes
Weather protection screen installed
q
Yes
Rotary field of fan
q
O.K.
Heat source brine / heat source water
Heat source volume flow ¹)
q
O.K.
Motor protection setting
A
Rotary field of heat source circulating pump
q
O.K.
Heat source filled, air-free and sealed
q
Yes
Brine
Frost protection down to
°C
Type of anti-freeze agent (please enter)
Water
Water quality OK ²)
q
Yes
Well units
q
Yes
Other heat source
q
Yes
Heat pump
Installation of condensate hose
q
O.K.
Decoupled from structure
q
Yes
Vibration decouplers of heating circuit and
heat source connections mounted
q
Yes
Solar heat system
q
No
q
Yes
1) checked with specifications
2) Report of water analysis must be submitted.
Heating
Volume flow ¹)
q
O.K.
Heating system designed for maximum
°C
Heating system filled, air-free and sealed
q
Yes
Low temperature heating
q
Yes
High temperature heating
q
Yes
All heating circuits can be opened
q
Yes
Forward flow tank
q
Yes
Return flow tank
q
Yes
Separating tank
q
Yes
Contents
l
Additional heating
kW
Domestic hot water
with heat pump
q
Yes
Request with thermostat
q
Yes
Request with sensor
q
Yes
Volume flow ¹)
q
O.K.
Heat exchanger surface
m²
Connections sealed
q
Yes
Electric
Rotary field, power network
q
clockwise
Protective measures checked
q
Yes
Rotary field of compressor
q
O.K.
Return flow sensor mounted
q
internal
q
external
Outdoor sensor mounted
q
No
q
Yes
We reserve the right to modify technical specifications without prior notice.
UK830500/190402 © Alpha-InnoTec GmbH
General checklist
