COP
Coeffiicient of performance / Leistungszahl
Qh (kW)
4
6
8
10
12
14
-10 -5 0 5 10 15 20 25 30
Temp„ (°C)
35°C
50°C
65°C
COP
1
2
3
4
5
6
7
8
-10 -5 0 5 10 15 20 25 30
Temp„ (°C)
Pe (kW)
0
1
2
3
4
5
-10 -5 0 5 10 15 20 25 30
Temp„ (°C)
∆p (bar)
0,0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5
“”
p” p”†
∆p (bar)
0,0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5
“„
p„ p„†
Legend: UK823000L/170408
“” Volume flow, heating water
“„ Volume flow, heat source
Temp„ Temperature, heat source
Qh Heating capacity
Pe Power consumption
COP Coefficient of performance / efficiency rating
∆p” / ∆p”† Free compression, heating circuit / free compression, heating circuit with cooling
∆p„ / ∆p„† Free compression, heat source / free compression, heat source with cooling
We reserve the right to modify technical specifications without prior notice.
UK830500/190402 © Alpha-InnoTec GmbH
Performance curves SWC 70H(/K)

Alpha-InnoTec SWC 60H Specifications
