14
Subject to change without notice | 83056600cUK – Translation into English of the original German operating manual | ait-deutschland GmbH
8. Remove 3 clips on the hydraulic connections.
9. Use spanner size SW 52 to unscrew the heating
ow.
10. Disconnect the hydraulic connections; to do this,
push the pipes downwards as far as necessary.
11. Remove the 2 side retaining screws.
12. Toprotecttheoorandmovethemodulebox(3)
more easily: place boards (4) under it, e.g. from
thepackagingmaterial.
13. Liftandholdnut(1)ontheheatingow.
14. Slowly and carefully pull out the module box by
the retaining loops (2). Ensure that none of the
pipes are damaged
2
3
4
1
1.
2.
