zero is required to ensure that the sorting is correct. If there are more than 99 items of the same
type, two preceding zeros are required (“001”).
It is not possible to apply names to power modules
3. Press the Re-number Modbus Table By Name button on the Full Data Set table. This sorts all the
Modbus data of the same type alphanumerically and reassigns addresses
4. Export a clone of the system and import to another system. On import the Modbus items are sorted
in the same way as is done when the Re-number Modbus Table By Name is pressed.
5. Perform Replace ADIO operation to transfer ADIO configuration of imported ADIO to existing ADIO
After importing the clone, the Modbus structure on the two identical systems is the same.
2.5. Modbus Reference
2.5.1. Full System Data Set Data Points
This section gives the data points for each type of item that is available through Modbus. Because of the
dynamic nature of the configuration, it is not possible to show a static Modbus table with addresses for a
system. Use the Export to CSV button on the web interface to generate and download a Modbus table
with addresses for a specific system. Each table has three columns:
• Name: the name of the data.
• Register: the Modbus register where the data resides.
• Format: the format of the data. To display data correctly, Modbus clients must have the right data
format specified in the correct order.
2.5.1.1. Data Points
Table 5. Controller Data Points
Name Register Format
Disk Almost Full 02:Input Status Boolean
Clock Error 02:Input Status Boolean
CAN Devices In Bootloader 02:Input Status Boolean
ADIO Comms Lost 02:Input Status Boolean
Temporary License In Use 02:Input Status Boolean
Temporary License Expired 02:Input Status Boolean
Required Feature License Missing 02:Input Status Boolean
Unassigned Modules 02:Input Status Boolean
Page 14 0350114-J0 Rev G
