Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
2.5.2.1. Data Points
This section documents the Modbus data values available for the limited data set.
Table 31. Limited Data Set Data Points
Decimal Address Register Name Format
30001 04:Input Register CT/397: Current 32-bit Floating Point
30003 04:Input Register System Voltage 32-bit Floating Point
30005 04:Input Register Total Load Current 32-bit Floating Point
30007 04:Input Register Total Capacity Installed in
Amps
32-bit Floating Point
30009 04:Input Register System Mode - (0) Un-
known, (1) No Battery, (2)
System Off, (3) Battery
on Discharge, (4) Battery
Conditioning, (5) Battery
Charging, (6) Battery on
Discharge Test
32-bit Floating Point
30011 04:Input Register Estimated Rectifier AC In-
put Voltage
32-bit Floating Point
30013 04:Input Register Estimated Battery Run-
time
32-bit Floating Point
30015 04:Input Register Last Discharge Duration 32-bit Floating Point
30017 04:Input Register Output Voltage Low Alarm
Limit
32-bit Floating Point
30019 04:Input Register Output Voltage High
Alarm Limit
32-bit Floating Point
30021 04:Input Register Battery Runtime Low
Alarm Limit
32-bit Floating Point
30023 04:Input Register AC Mains Voltage Low
Alarm Limit
32-bit Floating Point
30025 04:Input Register AC Mains Voltage Hight
Alarm Limit
32-bit Floating Point
30027 04:Input Register Battery: Capacity Rating 32-bit Floating Point
30029 04:Input Register Battery: Average Temper-
ature
32-bit Floating Point
30031 04:Input Register Battery: Current 32-bit Floating Point
Page 38 0350114-J0 Rev G
