Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
Table 20. DC System Battery Data Points (continued)
Name Register Format
• Unknown = 0
• NoBattery = 1
• Disconnected = 2
• Discharging = 3
• Charging = 5
• Battery Test = 6
• Float = 10
• Equalize = 11
• Boost = 12
Table 21. DC System Loads Data Points
Name Register Format
Inverter System Load: Load Volt-
age High
02:Input Status Boolean
Inverter System Load: Load Cur-
rent High
02:Input Status Boolean
Inverter System Load: Load Break-
er/Fuse Open
02:Input Status Boolean
Inverter System Load: Load Volt-
age Low
02:Input Status Boolean
Load: Load Voltage High 02:Input Status Boolean
Load: Load Current High 02:Input Status Boolean
Load: Load Breaker/Fuse Open 02:Input Status Boolean
Load: Load Voltage Low 02:Input Status Boolean
Inverter System Load: Current 04:Input Register 32-bit Floating Point
Ref. Load: Current 04:Input Register 32-bit Floating Point
Load: Current 04:Input Register 32-bit Floating Point
An example of each type of load is given in the table: Inverter System Load, Load and Referenced Load
(Ref. Load)
0350114-J0 Rev G Page 27
