Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
Table 5. Controller Data Points (continued)
Name Register Format
Duplicate SNMP Component Refer-
ence
02:Input Status Boolean
Restart Required 02:Input Status Boolean
Number Of Bit Errors High 02:Input Status Boolean
Memory Usage High 02:Input Status Boolean
CAN Module Communication Lost
Count High
02:Input Status Boolean
CAN Module Communication Lost
Count Very High
02:Input Status Boolean
Controller: Time Since Restart 04:Input Register 32-bit Floating Point
Table 6. Custom Data Data Points
Name Register Format
Custom Data: Result as Numeric 04:Input Register 32-bit Floating Point
Table 7. Timers Data Points
Name Register Format
Interval Timer: Output 02:Input Status Boolean
Delay Timer: Output 02:Input Status Boolean
Delay Timer: Delay Time Remain-
ing
04:Input Register 32-bit Floating Point
Table 8. Counters Data Points
Name Register Format
Down Counter: Input 02:Input Status Boolean
Up Counter: Input 02:Input Status Boolean
Down Counter: Output 04:Input Register 32-bit Floating Point
Up Counter: Output 04:Input Register 32-bit Floating Point
0350114-J0 Rev G Page 15
