Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
Table 26. AMPS HP System Data Points (continued)
Name Register Format
DC Group 4 Number Of Inverters
Failed
04:Input Register 32-bit Floating Point
DC Group 4 Number of Inverters
Detected
04:Input Register 32-bit Floating Point
Table 27. AMPS HP System Bypass Switch Data Points
Name Register Format
State 02:Input Status Boolean
Bypass Active 02:Input Status Boolean
Table 28. AMPS HP System Breakers/Fuse Data Points
Name Register Format
State 02:Input Status Boolean
Open Breaker/Fuse 02:Input Status Boolean
Table 29. AMPS HP System T2S Data Points
Name Register Format
CAN Serial Number 04:Input Register 32-bit Integer
# Communicating Inverters 04:Input Register 32-bit Floating Point
# Comms Lost Inverters 04:Input Register 32-bit Floating Point
Table 30. AMPS HP System TSI Inverters Data Points
Name Register Format
AC Output Status 04:Input Register 32-bit Floating Point
• On = 0
• Manual Off = 1
Page 36 0350114-J0 Rev G
