Modbus Integrator's Guide for the CXC HP | 2 - Using Modbus
Table 19. DC System Data Points (continued)
Name Register Format
Insufficient Capacity Remaining (A) 02:Input Status Boolean
Insufficient Capacity Remaining
(W)
02:Input Status Boolean
Missing Rectifier 02:Input Status Boolean
Rectifier AC Fail Count High 02:Input Status Boolean
Rectifier AC Fail Count Very High 02:Input Status Boolean
System Voltage 04:Input Register 32-bit Floating Point
Estimated AC Input Voltage 04:Input Register 32-bit Floating Point
Total Load Current 04:Input Register 32-bit Floating Point
Expected Load Current in AC Fail 04:Input Register 32-bit Floating Point
Battery Voltage 04:Input Register 32-bit Floating Point
Battery Current 04:Input Register 32-bit Floating Point
Total Output Current 04:Input Register 32-bit Floating Point
Total Output Power 04:Input Register 32-bit Floating Point
Total Capacity Installed (A) 04:Input Register 32-bit Floating Point
Total Capacity Installed (W) 04:Input Register 32-bit Floating Point
Estimated Capacity Remaining (A) 04:Input Register 32-bit Floating Point
Estimated Capacity Remaining (W) 04:Input Register 32-bit Floating Point
Average Rectifier Output Voltage 04:Input Register 32-bit Floating Point
Estimated AC Phase 1 Voltage 04:Input Register 32-bit Floating Point
Estimated AC Phase 2 Voltage 04:Input Register 32-bit Floating Point
Estimated AC Phase 3 Voltage 04:Input Register 32-bit Floating Point
Estimated Required Capacity 04:Input Register 32-bit Floating Point
Estimated Available Capacity 04:Input Register 32-bit Floating Point
Estimated Redundant Capacity 04:Input Register 32-bit Floating Point
Estimated Standby Capacity 04:Input Register 32-bit Floating Point
# Acquired Rectifiers 04:Input Register 32-bit Floating Point
# Sourcing Rectifiers 04:Input Register 32-bit Floating Point
# Failed Rectifiers 04:Input Register 32-bit Floating Point
