Alpha ALPHA6000 Series - Pd: Protection and Fault Parameters

Chapter 4 Parameter Index
http://www.acdrive-china.com
101
Function
code
Function
Name
LCD
Display
Range of settings
Defaul
t
Change
MODBUS
Address
PC.22
Linear speed
display
coefficient
Line speed
display
coefficient
0.1～999.9%
Linear speed =
Running
frequency ×PC.22
(no PG))
Linear speed =
Rotate
speed×PC.22
(PG)
Reference linear
speed = reference
frequency* PC.22
(no PG)
Reference linear
speed=reference
speed×PC.22
(PG)
Note: This setting
has no influence
to actual speed
100.0
%
○ 0D16
Pd: Protection and Fault Parameters
Function
code
Function
Name
LCD
Display
Range of
settings
Default Change
MODBUS
Address
Pd.00
Motor above
load
protection
mode
selection
Overload
protection
selection
0:Disabled
1:Common
motor (with
low speed
compensation
)
2:Variable
frequency
motor
(without low
speed
compensation
)
1
× 0E00
Pd.01
Electro
thermal
protective
value
Electro
thermal
protective
value
20～110%
100%
○ 0E01
