Chapter 5 Parameter Introductions
http://www.acdrive-china.com
149
P4.05 Analog input filter time constant 1 (AI1
Terminal)
Range: 0.01~50.00s0.05s
P4.06 Min analog value Input 2 (AI2 Terminal)
Range: 0.00~P4.080.10V
P4.07 Physical value 2 corresponding to Min
analog value Input
Range: 0.0100.0%0.0%
P4.08 Max analog value Input 2 (AI2)
Range: P4.0610.00V10.00V
P4.09 Physical value 2 corresponding to Max
analog value Input
Range: 0.0100.0%100.0%
P4.10 Analog input filter time constant 2 (AI2
Terminal)
Range: 0.0150.00s0.05s
P4.11 Min pulse value Input 3 (pulse input
Terminal)
Range: 0.00P4.13 0.00K
P4.12 Physical value 3 corresponding to Min
pulse value Input
Range: 0.0100.0%0.0%
P4.13 Max pulse value Input 3 (pulse input
Terminal)
Range: P4.1150.00kH50.00k
P4.14 Physical value 3 corresponding to Max
pulse value Input
Range: 0.0100.0%100.0%
P4.15 Pulse input filter time constant 3 (pulse
Input Terminal)
Range: 0.0150.00s0.05s
Note 1:
Min/Max virtual value of analog input is the Min/Max virtual value of the input
signals. If the actual value input is smaller than min value, the min value will be
treated as the Min virtual value of analog input. If the actual value input is greater than
the max value, the max value will be treated as the Max virtual value of analog input.
The max virtual value of analog input must be greater than the min.
Physical value corresponding to virtual value of analog input: The physical value can
be reference frequency, rotate speed, or pressure, etc.
The ac drive offers three groups of analog input signal. They are analog input terminal
AI1, AI2, and pulse. Users can define input /output curve of each channel. Totally, you
can define three curves.
The analog input of AI1 and AI2 can be voltage (010V) or current (020mA),
selected by the switches on the control board.(Switching SW1 at place 1 means OFF,
it corresponds to 0-10V. If SW1 is ON, it corresponds to 0-20mA.)
Through setting P4.01P4.04, P4.06P4.09 and P4.11P4.14, can defined two
characteristic linear curves. The positive and negative function is shown in Fig.5-4-1.
