Alpha ALPHA6000 Series - Page 18

Chapter 2 Installation and Wiring
http://www.acdrive-china.com
18
Category Terminal Name Functions Specifications
AI2
Analog
input2
GND)
AO1
Analog
output1
Be able to output
analog voltage
/current (total 12
kinds of
signals).Switch SW2
can select voltage or
current output mode.
Voltage output mode
is the default mode.
Refer to P4.16 for
details. (The
reference ground is
GND)
Analog
output
AO2
Analog
output2
(only
35R5GB/3
7R5PB～
3500G)
Be able to output
analog voltage
/current (total 12
kinds of
signals).Switch SW3
can select voltage or
current output mode.
Voltage output mode
is the default mode.
Refer to P4.17 for
details. (The
reference ground is
GND)
Output current
range: 0/4~20 mA
Output voltage
range: 0/2~10 V
