Alpha ALPHA6000 Series - Page 21

Chapter 2 Installation and Wiring
http://www.acdrive-china.com
21
Category Terminal Name Functions Specifications
X8
Multi-
function
input
terminal
8(only
35R5GB/3
7R5PB～
3500G)
DO
Open
collector
output
terminal
Multi-function pulse
output terminal can be
defined. See section
5.4, Chapter 5 for
details.
(The reference ground
is COM)
Optical-isolator
input
Collector open
circuit output
operating voltage
range : 0V～26V
The max put current
is 50mA
Output frequency
range: 0～50 KHz
Y1
Bi-directio
n open
collector
output
Y1(only
35R5GB/3
7R5PB～
3500G)
Multi-fun
ction
output
terminal
Multi-fun
ction
output
terminal
Y2
Bi-directio
n open
collector
output
Y2(only
35R5GB/3
7R5PB～
Multi-function on-off
output terminal can be
defined .See section
5.4, Chapter 5 for
details.
(The common
terminal is CME)
Optical-isolator
output
Operating voltage
range: 0 V～26 V
Max output current:
50 mA
Refer to the
description of
P3.14～P3.15 for
the using methods.
