Chapter 2 Installation and Wiring
http://www.acdrive-china.com
20
Category Terminal Name Functions Specifications
(The common
terminal is PLC)
0～30V
X6
Multi-
function
input
terminal
6(only
35R5GB/3
7R5PB～
3500G)
Be able to be defined
as multi-function on-
off input terminal.
See section 5.4,
Chapter 5 for details.
(The common
terminal is PLC)
Optical-isolator
input
Input resistance:
R=3.9 kΩ
Maximum input
frequency: 400 Hz
Input voltage range:
0～30V
Mult-func
tion input
terminal
X7
Multi-
function
input
terminal
7(only
35R5GB/3
7R5PB～
3500G)
Terminals X7 and X8
can be used as
common
multi-function
terminals, they can
also be used as high
frequency pulse
input. See section 5.4,
Chapter 5 for details.
(The common
terminal is PLC)
Max input
frequency: 50 KHz
Input voltage range:
0～30 V
