Appendix 4 MODBUS Communication
http://www.acdrive-china.com
231
●
Data List:
●Command data (Only write-in is possible)
Address Name BIT
Descriptions
0000H (Reserved)
0
Run command (1: Run 0: Stop)
1
Reverse command (1: REV 0: FWD)
2
External fault (1: External fault [EF0])
3
Fault reset (1: Fault reset)
4
Multi-function reference 1(P3.01 X1
Terminal function)
5
Multi-function reference 2(P3.02 X2
Terminal function)
6
Multi-function reference 3(P3.03 X3
Terminal function)
7
Multi-function reference 4(P3.04 X4
Terminal function)
8
Multi-function reference 5(P3.05 X5
Terminal function)
9
Multi-function reference 6(P3.06 X6
Terminal function)( Only 35R5GB/37R5PB
~ 3500G)
A
Multi-function reference 7(P3.07 X7
Terminal function) ( Only
35R5GB/37R5PB ~ 3500G)
B
Multi-function reference 8(P3.08 X8
Terminal function) ( Only
35R5GB/37R5PB ~ 3500G)
0001H
Run
Operation
Signal
C-F (Reserved)
* NOTE 1
0002H
Frequency
Reference
The unit is selected by the constant Pb.04 * NOTE 2
0003H
Communication PID feedback,
Data range 0-1000 corresponding to 0.0~100.0%.
Set PC.15 value to 1 for monitoring PID feedback by
ke
y
b
oard
0004H
Communication PID feed,
Data range 0-1000 corresponding to 0.0~100.0%.
Set PC.16 value to 1 for watching PID feed by
keyboard
