Alpha ALPHA6000 Series - Page 234

Appendix 4 MODBUS Communication
http://www.acdrive-china.com
234
Address Name BIT Content
0023H
Output
frequenc
Frequency reference before compensation
0024H
Output
fre
q
uenc
Frequency reference after compensation
0025H
AI1
analog
AI1 analog input(V)
0026H
AI2
analo
g
AI2 analog input(V)
0027H
Output
Output current (A)
Address Name BIT Content
0028H output voltage (V)
0029H Reference frequency (Hz)
002AH (Reserved)
0 Terminal X1 1:CLOSED 0:OPEN
1 Terminal X2 1:CLOSED 0:OPEN
2 Terminal X3 1:CLOSED 0:OPEN
3 Terminal X4 1:CLOSED 0:OPEN
4 Terminal X5 1:CLOSED 0:OPEN
5
Terminal X6( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
6
Terminal X7( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
7
Terminal X8( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
8 Terminal DO 1:CLOSED 0:OPEN
9
Terminal Y1( Only
35R5GB/37R5PB ~
3500G
)
1:CLOSED 0:OPEN
A
Terminal Y2( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
002BH
Terminal
status
B RELAY 1 1:CLOSED 0:OPEN
