Appendix 4 MODBUS Communication
http://www.acdrive-china.com
235
Address Name BIT Content
C
RELAY 2( Only
35R5GB/37R5PB ~
3500G)
1:CLOSED 0:OPEN
D-F
(Reserved)
002CH (Reserved)
0 DO 1:“ON” 0:“OFF”
1
Y1(Only35R5GB/3
7R5PB ~ 3500G)
1:“ON” 0:“OFF”
2
Y2(Only35R5GB/3
7R5PB ~ 3500G)
1:“ON” 0:“OFF”
3 RELAY 1 1:“ON” 0:“OFF”
4
RELAY2(Only
35R5GB/37R5PB ~
3500G)
1:“ON” 0:“OFF”
002DH
Multi-fun
ction
output
terminal
monitor
5-F (Reserved)
002EH-00
30H
(Reserved)
0031H DC bus voltage
0032H Output torque
0033H Rotate speed (r/min)
0034H Reference speed (r/min)
0035H Linear speed (m/s)
0036H Reference line speed (m/s)
0037H Output power
0038H PID feedback(% )
0039H PID feed(% )
003AH Setting length
003BH Actual length
003CH Exterior count
003DH～
003FH
(Reserved)
0040H～
004CH
Terminal state, 0040H ~ 004CH in turn corresponds to the
BIT0 ~ BITC 002BH
